Product Details
| Machine Models | MAX 5L | |||||
|---|---|---|---|---|---|---|
| ITEMS | unit | MAX2-5L | MAX3-5L | MAX4-5L | MAX6-5L | |
| Bottle Spec. | Cavity Qty. | CAV | 2 | 3 | 4 | 6 |
| Max. Bottle Volume | L | 5 | 5 | 5 | 5 | |
| Max. Neck size | MM | 55 | 55 | 55 | 55 | |
| Max. Bottle Diameter | MM | 180 | 180 | 180 | 180 | |
| Max. Bottle Height | MM | 350 | 350 | 350 | 350 | |
| Theoretical Output | BPH | 2200 | 3400 | 4400 | 6000 | |
| Molding Spec. | Pitch in Oven | MM | 63.5 | 63.5 | 63.5 | 63.5 |
| Bottle Pitch | MM | 200 | 200 | 200 | 200 | |
| Power | Heating Power | KW | 60 | 96 | 124 | 148 |
| Rated Total Power | KW | 75 | 110 | 142 | 162 | |
| Consuming Power | KW | 48 | 60 | 72 | 85 | |
| Compressed Air | Action Pressure | BAR | 7 | 7 | 7 | 7 |
| Low Pressure Consumption | m³/min | 1.5 | 1.5 | 1.5 | 1.5 | |
| Blowing Pressure | BAR | 25-35 | 25-35 | 25-35 | 25-35 | |
| High Pressure Consumption | m³/min | 8 | 9 | 12 | 16 | |
| Cooling Water | Cooling Water Pressure | BAR | 5 | 5 | 5 | 5 |
| Cooling Water Temperature | C | 12 | 12 | 12 | 12 | |
| Chiller Power | HP | 8 | 8 | 10 | 15 | |
| Machine Spec. | Machine Size | M | 5.2*2.0*2.4 | 6.3*2.0*2.4 | 8.8*2.0*2.4 | 9.8*2.0*2.4 |
| Machine Weight | KG | 6800 | 8200 | 9800 | 11500 | |
| Machine Models | MAX 10L | ||||
|---|---|---|---|---|---|
| ITEMS | unit | MAX2-10L | MAX3-10L | MAX4-10L | |
| Bottle Spec. | Cavity Qty. | CAV | 2 | 3 | 4 |
| Max. Bottle Volume | L | 10 | 10 | 10 | |
| Max. Neck size | MM | 55 | 55 | 55 | |
| Max. Bottle Diameter | MM | 220 | 220 | 220 | |
| Max. Bottle Height | MM | 430 | 430 | 430 | |
| Theoretical Output | BPH | 1500 | 2600 | 3600 | |
| Molding Spec. | Pitch in Oven | MM | 63.5 | 63.5 | 63.5 |
| Bottle Pitch | MM | 250 | 250 | 250 | |
| Power | Heating Power | KW | 96 | 110 | 140 |
| Rated Total Power | KW | 116 | 130 | 160 | |
| Consuming Power | KW | 58 | 68 | 78 | |
| Compressed Air | Action Pressure | BAR | 7 | 7 | 7 |
| Low Pressure Consumption | m³/min | 1.5 | 1.5 | 1.5 | |
| Blowing Pressure | BAR | 25-35 | 25-35 | 25-35 | |
| High Pressure Consumption | m³/min | 8 | 12 | 15 | |
| Cooling Water | Cooling Water Pressure | BAR | 5 | 5 | 5 |
| Cooling Water Temperature | C | 12 | 12 | 12 | |
| Chiller Power | HP | 8 | 10 | 15 | |
| Machine Spec. | Machine Size | M | 5.8*2.0*2.4 | 6.3*2.0*2.4 | 8.2*2.0*2.4 |
| Machine Weight | KG | 7500 | 8600 | 10600 | |
| Machine Models | MAX 20L | 3/5 GALLON | ||||
|---|---|---|---|---|---|---|
| ITEMS | unit | MAX1-20L | MAX2-20L | MAX1-5G | MAX2-5G | |
| Bottle Spec. | Cavity Qty. | CAV | 1 | 2 | 1 | 2 |
| Max. Bottle Volume | L | 20 | 20 | 20 | 20 | |
| Max. Neck size | MM | 80 | 80 | 80 | 80 | |
| Max. Bottle Diameter | MM | 300 | 300 | 300 | 300 | |
| Max. Bottle Height | MM | 500 | 500 | 500 | 500 | |
| Theoretical Output | BPH | 700 | 1300 | 250 | 500 | |
| Molding Spec. | Pitch in Oven | MM | 90 | 90 | 90 | 90 |
| Bottle Pitch | MM | 320 | 320 | |||
| Power | Heating Power | KW | 140 | 196 | 140 | 196 |
| Rated Total Power | KW | 152 | 220 | 152 | 220 | |
| Consuming Power | KW | 58 | 90 | 58 | 90 | |
| Compressed Air | Action Pressure | BAR | 7 | 7 | 7 | 7 |
| Low Pressure Consumption | m³/min | 1.5 | 1.5 | 1.5 | 1.5 | |
| Blowing Pressure | BAR | 25-35 | 25-35 | 25-35 | 25-35 | |
| High Pressure Consumption | m³/min | 8 | 14 | 6 | 10 | |
| Cooling Water | Cooling Water Pressure | BAR | 5 | 5 | 5 | 5 |
| Cooling Water Temperature | C | 12 | 12 | 12 | 12 | |
| Chiller Power | HP | 8 | 10 | 8 | 10 | |
| Machine Spec. | Machine Size | M | 5.8*2.0*2.4 | 8.8*2.0*2.4 | 5.8*2.0*2.4 | 8.8*2.0*2.4 |
| Machine Weight | KG | 7500 | 8600 | 7500 | 8600 | |
Due to continous technical development, specification would be updated without prior notify.
